Graphis Light
The ‘light’ is a single-sided glass panel with an aluminium structure, which is perfectly dustproof thanks to an innovative perimeter joint.
Rimadesio Graphis Light
How much does a Rimadesio Graphis Light sliding door cost?
RIMADESIO GRAPHIS LIGHT FROM £4,600 + VAT*
Graphis Light can be used as a single sliding door or combined across wider wardrobe and dressing-room openings. In multi-panel arrangements, each panel moves independently, rather than using the linked-opening mechanism available in some other Rimadesio sliding systems.
Cost based on a 3-panel arrangement, H2400mm x W3000mm, hung from a 3-track flush-fit ceiling rail. Frame Structure and handle: aluminium / glass, transparent.
*Cost does not include specialist services and installation.
Graphis Light Sliding Door
Graphis Light sizes and options
- Glass panel: Single 4 mm tempered-glass panel. The lacquered glass is not transparent; under strong backlighting, lighter colours may allow some light to show through.
- Door structure: Extruded aluminium.
- Handle: Built-in metal handle with a tempered lacquered-glass insert in the same finish as the panel.
- Perimeter joint: Silicone rubber.
- Dust brushes: Polypropylene.
- Side runner: Aluminium.
- Floor guide: Patented retractable floor pin.
- Sliding mechanism: Sliding carriage.
Specification Sheets
What options are there?
Panel Dimensions
Every Rimadesio Graphis Light sliding door is custom-made to meet the architectural requirements of the client’s property.
Sliding panel minimum width
500 mm
Fixed panel minimum width
320 mm
Maximum panel width
1500 mm
Maximum panel height
2925 mm
Handle
Single recessed handle
Maximum height of 2925mm
Handles
Single recessed handle
For additional documentation supporting the specification of Rimadesio Velaria sliding doors, click the button below.
Want to know more about a Graphis Plus Sliding Door installation?
You can always call us directly on 01225 433511 or email us at info@hobsonschoice.co.uk
Can Graphis Light be fitted to an existing opening?
Yes, in many cases. Graphis Light is made to measure, and Rimadesio allows its sliding panels to use ceiling-mounted, wall-mounted or recessed/built-in rails. Graphis Light can often be added to an existing opening. The appropriate rail system depends on the construction of the wall and ceiling, the available space for the panels to slide and the finish you want to achieve.
What ceiling preparation is required?
It depends on the rail you choose. There are three relevant installation routes. A ceiling-mounted rail fixes directly beneath the ceiling; Rimadesio’s telescopic adjustment system provides 25 mm of vertical adjustment to level the rail and compensate for some ceiling variation. A recessed rail sits within the ceiling and therefore needs a suitable false-ceiling/recess detail. Alternatively, a wall-mounted rail can avoid fixing the track to the ceiling altogether.
Does it need a floor track, floor pin or other floor preparation?
The panels are top-hung, so there is no continuous floor track. A discreet floor guide or retractable locating pin is required to stabilise the panel.
What are typical lead times?
We allow approximately 8–12 weeks from order for manufacture and delivery. Lead times can vary depending on the specification and Rimadesio’s current production schedule.
Can a single Graphis Light door/system be purchased for one opening?
Yes. Graphis Light can be specified as a single sliding panel for one opening or as part of a larger multi-panel arrangement.
